Biochemistry Analyzer
HTSH-2000

Biochemistry Analyzer HTSH-2000

Product Feature

  • Reagent-Sample Tray

    40 Reagent positions, 48 Sample positions

    Allow mixed display of all kinds of samples

    37±0.1℃, real-time monitor

  • Reaction Tray

    50 Reaction positions

    Automatically monitor on the remaining circulating cooling refrigeration

  • Reagent/Sample Filling Mechanism

    Special coating to avoid contamination

  • Stirring Mechanism

    Liquid level sensor & Anti-collision function

    Reagent volume real-time detection

    Automatic cleaning function

  • Automatic Cleaning Mechanism

    Automatic 8 sections washing of reaction cups

    Plugging and automatic cleaning functions for washing probe

Technical Specifications


Description

Parameters

Sample Type

Whole Blood, Serum, Plasma, Urine, CSF, Hydrothorax, Ascities, etc.

Test Speed

200 Test/Hour

Simultaneously Test Items

38

Sample Position

48

Reagent Position

40

Reaction Position

50

Sample Volume

1.5-50 μL, with 0.1μL step

Reagent Volume

10-350 μL, with 1.0μL step

Reaction Volume

240~500 μL

Light Source

12V 20VA Halogen Lamp

Photometry Range

0-4.0 Abs

Wavelength

9 Wavelengths (340, 405, 450, 510, 546, 578, 620, 660, 690nm)

Temperature Control

37±0.1℃

Cleaning System

6 Stage cleaning

Power Supply

100-240V AC, 50/60Hz, 1KVA Three-core power cord, with good grounding

Dimension (L×W×H)

622mm×428mm×527mm

Weight

47.5 Kg
