225 Test/Hour
Time to first report short as 12 min
Covers only 0.6 m2, fastest speed among similar sizes
Brushless motor technology, reaction buffer thoroughly mixed within 2 seconds
Cutting-edge cleaning technology minimizes sample needle contamination rate at < 0.1ppm
Patented light-avoidance structure, accelerated light-avoidance result reading
Automatic sample scanning
One-click auto maintenance
Real-time consumable monitoring
General Specifications | |
Detection Principle | Direct chemiluminescence of magnetic particle acridinium ester |
Test Speed | 225 Test/Hour |
Floor Space | 0.6 m2 |
Floor Efficiency Ratio | 360 Tests/Hour/m2 |
Power | AC 220V, 1450VA |
Dimension (L×W×H) | 1060mm×590mm×720mm |
Weight | 105 Kg |
Sample Module | |
Sample Loading | Samply Tray |
Sample Type | Serum, Plasma |
Samply Addition Method | Permanent Steel Needle |
Sample Position | 60 |
Reagent/Sample Needle Function | Liquid level detection, Residue monitor, Intelligent anti-blocking, Intelligent anti-collision, Empty pipette monitor |
Sample Addition Range | 5~200 μL |
Dilution Function | Support auto dilution and fixed multiple dilution, dilution ratio 1:2~1:400 |
Reaction Module | |
Reaction Cup Storage | 700 |
Simultaneously Analyzing Items | 20 |
Incubation Position | 131 |
Incubation Method | Matrix solid direct heating |
Reaction Buffer Mixing | Cutting-edge brushless motor technology, reaction buffer thoroughly mixed within 2 seconds |
Reagent Module | |
Reagent Loading Method | Integrated loading position |
Reagent Recognizing Method | RFID Radio Frequency Scanning |
Reagent Position | 20 (integrated reagent bottle) |
Reagent Refrigerating Temperature | 2~8 ℃ Reagent tray cools independently while analysis module is in sleep |
Evaporation prevention | Bionic heart valve-type soft cap, effectively preventing reagent evaporation |
Reagent Needle Function | Liquid level detection, Residue monitor, Intelligent anti-collision, Empty pipette monitor |
Needle Cleaning | Dual-flow waterfall type and turbine power combined cleaning technology |
Reagent Addition Volume | 5~200 μL |
Calibration & QC | Auto calibration and quality control |
